XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale

›

‹

›

XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale
XCMG XE1250 Mining Excavator
Bucket capacity: 5.2-7.0m³
Operating weight:115000kg
Engine Model:CUMMINS QSK23
Gross Power:567kw/1800r/min
Walking speed:3.5/2.4 km/h
Max. digging height:12500mm
Max. digging depth:8110mm
Max. digging distance:13470mm
Transport Dimension:14610×5470×6160mm
Inquiry Now →

Product Description

XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale


XCMG XE1250 EXCAVATOR SPECIFICATIONS
Operating weight115000Kg
Bucket capacity5.2-7.0m³
Engine Model engineCUMMINS QSK23
Direct Injection√
Four strokes√
Water cooling√
Turbo-charging√
Air to air intercooler√
No. of cylinders6
Rated power/speed567/1800kw/rpm
Maximum torque/speed3468/1350N.m/rpm
Displacement23.15L
Main performance Travel speed3.5/2.4km/h
Swing speed5.2 r/min
Gradeability30°
Ground pressure143kPa
Bucket digging force597kN
Arm digging force470kN
Maximum traction force746kN
Hydraulic system Main pumpThree piston pumps
Rated flow of main pump3×531L/min
Main safety valve pressure34.3MPa
Travel system pressure34.3MPa
Swing system pressure28MPa
Pilot system pressure3.9MPa
Oil Capacity Fuel tank capacity1460L
Hydraulic tank capacity640L
Engine oil capacity75L
Appearance size Overall length14610mm
Overall width5470mm
Overall height6160mm
Width of platform3450mm
Length of crawler6500mm
Total width of chassis4600mm
Track shoe width700mm
Wheel base of crawler5090mm
Track gauge3900mm
Counterweight clearance1880mm
Min. ground clearance1070mm
Min. tail swing radius4850mm
Height of crawler1710mm
Working range Max. digging height12500mm
Max. dumping height7990mm
Max. digging depth8110mm
Maximum depth cut for (8 ft) level bottom7980mm
Max. vertical wall digging depth5390mm
Max. digging radius13860mm
Min. swing radius6770mm
Standard Length of boom7550mm
Length of arm3400mm
Bucket capacity7m³
OptionalLength of boom9000mm
Length of arm3600mm
Bucket capacity5.2m³(Rock Bucket) 5.8m³(Rock Bucket)
PackingNude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice


XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale

XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale

More energy-conservation and environmental protection
Imported engine with original packing has features of powerful force and high efficiency. Low noise and low emission can greatly reduce the pollution to the environment. Compared with other brands of the same level, it has greater digging force, rotary force, rotary force and traction force, which can ensure that the machine can work quickly and efficiently. It can meet all the application requirements. Blending with proven, sturdy and durable parts and delicate manufacturing process, higher reliability and efficiency can be achieved.

More efficient return
By use of mature and reliable negative flow control system, the flow distribution is provided by multi-port valve to all acting cylinders through the three pump converging, whereby the powerful digging ability and excellent working performance are maintained.

High quality integrated electric system, with higher indicator and electric centralized control, the design is more concise and the system is more reliable.

More reliable and durable
With boom and arm reinforced and key parts adopted with integration steel casting.Through structural optimization, stress concentration is reduced to ensure equipment reli- ability under severe conditions.

Standard heavy-load rock bucket,adopting the high strength steel and with cutting parts reinforced,is sturdy and durable enough to prolong the service life greatly.

XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale

XCMG Official 115 Ton Crawler Excavators Xe1250 Chinese New Mining Hydraulic Excavator for Sale
