XCMG official 9ton water well drilling rig machine XSL3/160

›

‹

›

XCMG official 9ton water well drilling rig machine XSL3/160
Water Well Drilling Rig
Model:XSL3/160
Max. diameter of working floor:φ330mm
Drilling Depth:300m
Engine:YUCHAI YC4A125-T30,92/2200kw/rpm
Max. Speed:2.4km/h
Grade ability:39%
Gross vehicle weight:12500kg
Transport Size(LxWxH):6050*1800*2400mm
Inquiry Now →

Product Description

XCMG official 9ton water well drilling rig machine XSL3/160

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

XCMG official 9ton water well drilling rig machine XSL3/160


XSL3/160 Water Well Drilling Rig configuration list
ParameterUnitXSL3/160
Drilling capabilityDrilling depthm300(φ89)
Max. diameter of working floormmφ330
Feeding systemMax. liting capacitykN160
Max. feeding capacitykN80
Max. lifting speedm/min32(25)
Max. feeding speedm/min60(48)
Strokemm3800(7000)
Top driveMax. torqueN.m6600/3300
Max. speedr/min95/190
I.Dmmφ45
Deck engineType
YC4A125-T30
Rated powerkW92
Tool winchHoisting capacitykN15
Breakout deviceMax. breakout torqueN.m18000
Mud pipeI.Dmmφ55
Max. pressureMPa8
ChassisHighest speedkm/h2.4
Max. climbing gradient%39
Max. ground clearance of crawlermm1000
Max. inner distance between front support legsmm2600
Max. iner dstance between back support legsmm2700
Working dimensionmm3980*3130*6500(3980*3130*8100)
Transportation dimensionmm4450(3980)*1800*2400(6050(3980)*1800*2400)
Weightt8.7(9.7)
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice


XCMG official 9ton water well drilling rig machine XSL3/160

XCMG official 9ton water well drilling rig machine XSL3/160

XSL series deep(water) well drlling rig uses full hydraulic control and the top drive to drive the rotation of drilling tools with very high drilling efficiency.

Reasonable overall layout uses the tractor-mounted or all terrain chassis for transportation with good maneuverability. Very flexible in difficult roads, it can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, shallow layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation or salvage work.

The top-mounted driving head principal shaft has a great drift diameter,which is suitable for many kinds of construction work such as slurry drilling, air drilling, and air foam drilling, meeting the demands of well-drilling in different terrain strata.

XCMG official 9ton water well drilling rig machine XSL3/160
