60ton 3 Axles Side Wall/Drop Side/Cargo/Side Board Truck Semi Trailer Three axles 60 ton Bulk Grain Bin Trailer

›

‹

›

60ton 3 Axles Side Wall/Drop Side/Cargo/Side Board Truck Semi Trailer Three axles 60 ton Bulk Grain Bin Trailer
Three Axle Sidewall Semi-Trailer
Total outside approx.:13000*2500*2860mm
Dead weight approx.:8900kg
Payload approx:60000kg
Axles: 20Ton *3axles
Tire:12.00R20 *12 units
Bucket dimensions:
13000*2500*1400mm
Inquiry Now →

Product Description

60ton 3 Axles Side Wall/Drop Side/Cargo/Side Board Truck Semi Trailer Three axles 60 ton Bulk Grain Bin Trailer

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

60ton 3 Axles Side Wall/Drop Side/Cargo/Side Board Truck Semi Trailer Three axles 60 ton Bulk Grain Bin Trailer


THREE AXLE SIDE WALL SEMI TRAILER
PARAMETERS
Tare weight8900kg
Payload60-70Ton
Overall Size13000mm*2500mm*2700mm
Inside Size13000*2500*1400mm
Main beamHeavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-Arc processes.Upper flange 16mm;Bottom flange 18mm;Middle Flange 12mm ,Height 500mm;
Side beam16# channel steel(U-steel)
Cross member10# channel steel(U-steel)
Floor3mm checkered plate
Side wallHeight 1400mm thickness 2mm
Front boardManufacture Standard Height 1400mm
AxleFUWA  brand 20T *3 axles
SuspensionMechanical suspension American type
Leaf springLeaf spring 12pcs*120mm*16mm
Tyre1200R20 *12units
Wheel rim8.5-20 *12pcs
Kingpin2"/3.5" bolt-in king pin Optional upon choice
Landing gear28T two-speed, manual operating ,heavy duty landing gear
Braking systemRE6 relay valve ;T30/30 spring brake chamber;40L air tanks .Parking braking spring energy, compressed air operating on rear wheels
ABSNo.  Optional upon choice
Electrical systemVoltage 24V, Receptacle 7 ways (7 wire harness),LED lights,One set 6-core standard cable.
PaintingComplete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint,Use high-grade polyurethane paint,wax spray.
Twist lock12units or As clients order
AccessoriesOne standard tool box.One spare wheel carrier chained mode.One crank.One shaft head wrench.Rope hook casting model.Tight rope device *10units per side.
OtherAccording to requirtments
PackingNude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice


60ton 3 Axles Side Wall/Drop Side/Cargo/Side Board Truck Semi Trailer Three axles 60 ton Bulk Grain Bin Trailer

We are the top one and professional semi-trailer supplier.

 We can give you better product and favorable price.

 SINOCTM Vehicle has successfully entered into over 50 countries around the world.



 The sidewall cargo semi trailer use to load a wide range of products and materials, like sand, bags, poultry etc. Also the some bulk cargo, very widely used in the transportation industry. Suitable for the mid/long distance transportation of the mid/heavy duty and bulk cargo. The high side cargo trailer can be added with a container turn lock to transport the container.



Two axle sidewall trailer, Three axle dropside trailer, 4 axle high side trailer, grain trailer and the sidewall drawbar trailer. And load capacity has 30/40/60/80/100 tons for your choice. Customizable side wall height.

60ton 3 Axles Side Wall/Drop Side/Cargo/Side Board Truck Semi Trailer Three axles 60 ton Bulk Grain Bin Trailer

Our produce Bulk Grain Bin Trailer, to deliver the large mount of grain, like barley, corn, beans etc. Grain flatbed trailer with side panels from China. We produce Bulk Grain Bin Trailer for wheat transport and the side wall can be opened from upsides and also transport the barley, grain, maize corn, beans etc. Also we design the small grain doors inside the side panels, easy to unload the grain there.

Our Grain side wall cargo trailer adopt WABCO brakes, JOST landing leg, and FUWA axles

60ton 3 Axles Side Wall/Drop Side/Cargo/Side Board Truck Semi Trailer Three axles 60 ton Bulk Grain Bin Trailer
