Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer

›

‹

›

Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer
Three Axle Sidewall Semi-Trailer
Total outside approx.:12700*2500*2860mm
Dead weight approx.:6800kg
Payload approx:60000kg
Axles: 13Ton *3axles
Tire:12R22.5 *12 units
Bucket dimensions:
12500*2500*800mm
Inquiry Now →

Product Description

Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer


THREE AXLE SIDEWALL SEMI TRAILER SPECIFICATIONS
Dimension12700mm*2500mm*2860mm
Loading Capacity (T)≤ 60 T
Axle13 T, FUWA
Rim9.00-22.5 9.75-22.5(special for export market )
Tire12.00R22.5/ 315 80R22.5 (special for export market )
SuspensionMechanical suspension  (China brand or BPW brand )
Spring leaf90(W)mm*13(Thickness)mm*10 Layer
Kingpin 2.0 or 3.5inch bolts type
Support leg China brand 28Tons (Double speed)
Main beamHeight: 500mm, upper plate is 14mm, middle plate is 8mm,Down plate is 16mm; Material is Q345B Steel.
Side beam16mm or 18mm channel steel (Material is Q235steel).
Bottom Platform3mm diamond steel plate
Side Wall600mm-1500mm ,or can be do box type ,for choose
Brake chamberWABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); One piece of 45L air tanks
ABSOptional
Twist LocksFour, Eight or Twelve pieces (Lifting type or Twist Screw Type), optional
ValveWABCO valve
LightLED light (special for export market )
Voltage24V
Receptacle7 ways (7 wire harness)
ToolboxOne piece, 1m×0.5m×0.5m (Size can be chosen freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve, and 1 unit cranking bar)
PaintingComplete Chassis sandblasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
PackingNude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice


Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer

 The sidewall cargo semi trailer use to load a wide range of products and materials, like sand, bags, poultry etc. Also the some bulk cargo, very widely used in the transportation industry. Suitable for the mid/long distance transportation of the mid/heavy duty and bulk cargo. The high side cargo trailer can be added with a container turn lock to transport the container.



Two axle sidewall trailer, Three axle dropside trailer, 4 axle high side trailer, grain trailer and the sidewall drawbar trailer. And load capacity has 30/40/60/80/100 tons for your choice. Customizable side wall height.

Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer

Our Side Wall Trailer is your ideal partner for multipurpose solution catering to vast range of applications including Cement Bags, Agri bags, Tiles, Jumbo bags, steel coils, pet coke, etc.

Its higher payload carrying capacity, better mileage and availability of different product variants catering to varying customer's needs. The vehicle provides you with longer tyre life, high fuel efficiency and less maintenance cost which gives you higher revenue and lower operating cost, substantially increasing your overall profit.

Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer

Other products:

1. Dump Truck / Tipper Truck

2. Hohan tractor Truck/ prime mover truck

3. Truck with crane / Truck mounted crane

4. Oil Tank Truck / Fuel Tanker Truck

5. Water truck / Water Tank Truck / Water Sprinkler Truck

6. Concrete Mixer Truck

7. Van truck / Insulated truck/ Refrigeration truck

8. Fecal suction truck / Sewage suction truck

9. Cement Powder Tank truck/ Bulk cement trailer

10. High-altitude operation truck

11. Semi Trailer ( flat bed trailer / skeleton trailer / dump trailer / side wall trailer / low bed trailer / container trailer, etc. )

Side Wall Semi Trailer /Three Axles Side Wall Cargo Truck Semi Trailer
