SAM956 Wheel Loader 5T
SAM956 Wheel Loader
Bucket capacity:3.3m³
Operating weight:5000kg
Engine Model: Weichai SteyrWD10G220
Rated Power:162kW/2400/rpm(Weichai )
Overall weight:16500kg
Overall dimension (L×W×H):8247×3050×3416mm
Inquiry Now →

Product Description

企业横幅 6-2.jpg

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

新组合 1.jpg


SAM956 WHEEL LOADER SPECIFICATIONS
Performance
rated loading5000kg
overall weight16500kg
rated bucket capacity3.3m3
maximum tractive force152KN
maximum breakout force≥170KN
maximum grade ability30°
maximum dump height3150mm
maximum dump reach1250mm
overall dimension (L×W×H)8247×3050×3416mm
minimum turning radius6640mm
Engine
modelWeichai SteyrWD10G220
typelnline  water cooling dry cylinder  injection
No. of cylinder-bore/stroke6-126×130mm
rated power162kw--2400r/min
maximum torque860N.m
min fuel-consume ratio≤215g/kw.h
Transmission system
torque converterYJ375
gearbox modePower shift normally engaged straight gear
gear shift4 forward shift  4reverse shift
maximum speed38km/h
Drive axles
main reducing modebevel gear grade 1reduction
decelerating modeplanetary reduction,grade 1
wheel base (mm)3200mm
wheel tread2250mm
ground clearance450mm
Hydraulic system
system working pressure18MPa
boom lifting time5.95±0.2s
total time10.95±0.5s
fuel tank capacity300L
function of leveling automatically yes
Brake system
service brakeair assist disc brake on 4 wheels
parking brakeManual disk brake
Tyre
type specification23.5-25
front tyre pressure0.4Mpa
rear tyre pressure0.35Mpa
PackingNude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice


新组合 2.jpg

Focusing on customer value and emphasizing customer experiences, our loader is the first-choice equipment for the production organization in the fields of ports, mines, engineering constructions, and logistics.



1. Our exclusive high torque and high efficiency drive chain features reasonable matching.

2. Our characteristic super-heavy-load structure parts are free of redundant weight.

3. With extended wheelbase, the working capacity and stability are leading the industry.

4. The centering design of main hinge joints reduces the turning radius and lowers the tire wear and energy consumption.

5. The ergonomically design cab adopts integral skeleton structure, delicate interior trim parts, and sound insulation and noise reduction measure, featuring broad visual field, super-large space, and high operation comfort.

6. The diversified configurations and complete attachments comprehensively adapt to the construction needs in different regions and under different working conditions.

新组合(23) 1.jpg
