XCMG TY320 BULLDOZER 320hp 40T
XCMG TY320 BULLDOZER
Operating weight: 39800kg
Engine model: CUMMINS NT855-C360S10
Rated power: 245kw / 2000rpm
Blade width:4130mm
Max digging depth:560mm
Scraper capacity:11.7m³
Overall dimensions:8916x4130x3695mm
( with ripper )
Inquiry Now →

Product Description

企业横幅 6-2.jpg

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

新组合 1.jpg


XCMG TY320 BULLDOZER SPECIFICATIONS
ENGINE
ModelCummins NT855-C360S10; In-line, water cooled 4-cycle, overhead valve direct injection, turbocharged diesel
Rated power245kw / 2000rpm
Number of cylinders6—139.7x 152.4 mm (bore x stroke)
Piston displacement14L
Maximum torque1509N.m@1400rpm
     POWER TRANSMISSION SYSTEM
Torque converter3-element, 1 stage, 1 phase
TransmissionPlanetary type, multi-late clutch, forced lubrication
Main driveSpiral bevel gear, single-stage speed reduction, splash lubrication
Steering clutchWet, multi-disc, spring loaded, hydraulically separated, hydraulic control
Steering brakeWet, floating, direct on-off hydraulic inter-linking operation
Final drive2-stage speed reduction of spur gear, splash lubrication
         TRAVEL SPEED
Gear1st2nd3rd
Forward0-3.6km/h0-6.6km/h0-11.5km/h
Reverse0-4.4km/h0-7.8km/h0-13.5km/h
UNDERCARRIAGE SYSTEM
TypeEight-beam swing,balanced beam suspension structure
Carrier rollers(each side)2 each side
Track rollers(each side)7 each side
Width of track shoes560mm
Grouser height80mm
Track gauge2140mm
HYDRAULIC SYSTEM
Maximum pressure13.7Mpa
Pump typeGear pump CBZ4200
Discharge355L/min
Bore of working cylinder * no140mm * 2  225mm*1
BLADE
Blade typeStraight tilt ( STANDARD )
Dozing capacity11.7m3
Blade width4130mm
Blade height1590mm
Maximum drop below ground560mm
Maximum tilt adjustment>1000 mm
Weight of blade2700 kg
DIMENSIONS
Dimension8916x4130x3695( with ripper )
PackingNude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice


新组合 2.jpg

Performance Characteristics:

* The high reliability power shift transmission, the stable hydraulic torque converter, and two-stage spur gear final drive feature high power transmission efficiency.



* The engine can run normally and reliably under all load conditions and all hot environments required by the user, without overheating.



* It can realize the automatic diagnosis and whole-process monitoring of the malfunctions. The integrally injection molded instrument panel integrates the A/C, electric devices, and instruments, featuring beautiful appearance and high grade.



* The full box-type main frame with application of high performance materials and high strength castings features high carrying capacity against impact load and bendingmoment and the high quality welds guarantee the life cycle of the main frame.

新推土机组合 1.jpg
