SHANTUI SD13 BULLDOZER 130hp
SHANTUI SD13 BULLDOZER
Compact, reliable , durable.
Engine model: Shangchai SC8D143G2B1
Rated power: 95.5 kW/1900 rpm
Operating weight: 13.7 t
Inquiry Now →

Product Description

企业横幅 6-2.jpg

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

新组合 1.jpg


SHANTUI SD13 BULLDOZER SPECIFICATIONS
ENGINE
ModelShangchai SC8D143G2B1Water-cooled, in-line, 4-cycle, direct injection and turbocharged
Rated power95.5kw / 130hp
Number of cylinders6-114x135mm ( bore x stroke )
Piston displacement8.27L
Min. Fuel consumption228g/kW.h
Maximum torque674N.m@1300rpm
POWER TRANSMISSION SYSTEM
Torque converter3-element, 1 stage, 1 phase
TransmissionForced connected, planetary gear
Main driveSpiral bevel gear, splash lubrication
Steering clutchWet, multi-disc, spring loaded, hydraulic helping operation, mechanical separating, linking steering brake
Steering brakeWet, floating, band type foot stepping brake with hydraulic helping
Final drive2-stage speed reduction of spur gear, splash lubrication
TRAVEL SPEED
Gear1st2nd3rd
Forward0-3.2km/h0-5.9km/h0-9.8km/h
Reverse0-3.9km/h0-7.1km/h0-11.9km/h
UNDERCARRIAGE SYSTEM
TypeSprayed beam, suspended structure of equalizer
Carrier rollers2 each side
Track rollers6 each side
Track typeSingle grouser, dry type
Width of track shoes460mm
Pitch190mm
HYDRAULIC SYSTEM
Maximum pressure14Mpa
Pump typeGear pump
Discharge180L/min
Bore of working cylinder * no90mm * 2
BLADE
Blade typeStraight-tiltAngle
Dozing capacity3.7m33.4 m
Blade width3185mm3745mm
Blade height1090mm915m
Maximum drop below ground590mm590mm
Maximum tilt adjustment400mm400mm
RIPPER ( OPTIONAL )
Max digging depth of 3 shank ripper467mm
Max lift above ground559mm
Weight of 3 shank ripper1421kg
PackingNude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice


新组合 2.jpg

The SD13 gets mid-range volume jobs done in record time. A smaller version of our best-selling SD16 line. the SD13 delivers all the durability and reliability of its larger cousin series. With a high-power, high-efficiency. turbocharged engine featuring a large-torque reserve coefficient, the 130 hp SD13 is ready for work.Its extended track ensures low ground pressure, high reliability and strong traction while the comfortable wide visibility hexahedron cab and integrated dashboard design help keep operator productivity at peak levels.
